PAN AMERICA 1250 SPECIAL ST

SEE THE UNSEEN.

The 2025 Harley-Davidson® models represent the future of motorcycling. With upgraded engine performance, cutting-edge safety features, and state-of-the-art technology, this year's lineup pushes the boundaries of what's possible on two and three wheels.

Where touring becomes detouring, and everything is a road. The Pan America™ 1250 Special ST motorcycle is our premier two-wheel multi-tool built to endure, designed to explore, and engineered for adventure. We are calling it Special for a good reason. Enhanced and refined for on-road use–lowered, tuned, and now with 17-inch wheels for incredible handling and high-performance tires. The Pan America 1250 ST is still purpose-built, just for a different purpose.

FEATURES:
• Upright riding position.
• Mid-mount foot controls.
• Passenger seat.
• Frame-mounted fairing.

REVOLUTION® MAX ENGINE
The liquid-cooled Revolution Max 1250 has a broad powerband with 149 horsepower and 91ft-lb of torque at its peak. Integrated into the chassis as a load-bearing element, this engine not only shaves off weight but also improves rigidity for a more responsive ride.

ADAPTIVE RIDE HEIGHT
Standard on North American models, Adaptive Ride Height (ARH) drops one inch in a stopped position, allowing you to mount or dismount with ease and confidence.

RIDE MODES
Integrated technologies do not overshadow the riding experience, they enhance it: Adaptive Ride Height, Rider Safety Enhancements, Bluetooth® audio, and much more.

COLOR OPTIONS:
• Billiard Gray with Black Trim
• Vivid Black with Black Trim
• Brilliant Red with Black Trim

Vehicles depicted may differ from vehicles manufactured and delivered. Specifications and prices listed may differ from specifications and prices of vehicles manufactured and delivered. All product descriptions (including depictions, specifications, dimensions, measurements, ratings, and competitive comparisons) are based on available information at the time of publication. Although such descriptions are believed correct, errors and changes can occur and complete accuracy cannot be guaranteed. Harley-Davidson may make changes at any time to prices and specifications and may change or discontinue models, without notice and without incurring any obligation. Please check with your dealer for complete product details and the latest information.

DIMENSIONS: | Length:88.2 in | Width:35.3 in. | Ground Clearance:6.7 in. | Rake:25 | Trail:3.7 in. | Wheelbase:61.8 in. | Tire, Type:Michelin®Scorcher "Sport" | Tires, Front Specification:120/70ZR17 58W | Tires, Rear Specification:180/55ZR17 73W | Fuel Capacity:5.6 gal. (21.2 l) | Oil Capacity (w/filter):4.75 qt. (4.5 l) | Weight, In Running Order:542 lb. | ENGINE: | Engine Type:Revolution® Max 1250 | Bore x Stroke:4.134 in. (105 mm) x 2.846 in. (72.3 mm) | Displacement:76.4 cu in (1,252 cc) | Compression Ratio:13 to 1 | Fuel System:Electronic Sequential Port Fuel Injection (ESPFI) | Exhaust:2-into-1-into-1; catalyst in header | CHASSIS: | Front Fork:47mm inverted fork with electronically adjustable semi-active damping control. Aluminum fork triple clamps | Rear Shocks:Linkage-mounted monoshock with automatic electronic preload control and semi-active compression & rebound damping | Wheels, Optional Style Type:N/A | Wheels, Front Type:Aluminum cast, satin black | Wheels, Rear Type:Aluminum cast, satin black | Brakes, Caliper Type – Front:Radially mounted, monoblock, 4-piston caliper | Brakes, Caliper Type – Rear:Floating, single piston caliper | PERFORMANCE: | Engine Torque Testing Method:J1349 | Engine Torque:94 ft-lb (127 Nm) | Engine Torque (rpm):6,750 | Horsepower:149 HP / 111 kW @ 8750 rpm | Lean Angle, Right (Deg.):37 | Lean Angle, Left (Deg.):37 | Fuel Economy Testing Method:Estimated City/Hwy | Fuel Economy:46 mpg (5.1 l/100 km) |
